tipologia luce

Oblò

Oblò

prodotto

Oblò

Architectural outdoor
Last update: 30/05/2025
Description
A series of ceiling recessed fittings by minimalist design: all its components are engineered to have minimum thicknesses. The result is a product by the ephemeral grazing presence on the surface of the ceiling. The narrow external ring makes OBLO a product from the discreet presence even when it is off. It is available with light sources in dynamic or monochromatic light.
Gallery
product
product
product
Oblò
Overview

Die-cast body manufactured in aluminium alloy with very low copper content. front locking trim in painted steel. No visible screws and reduced recessing depth. Subjected to galvanic anodizing treatment divided into distinct phases: mechanical satin finishing, surface degreasing, anodic oxidation and final sealing.

  • IP65
  • IK08
  • LED
Details
Dettaglio
Product with IP65 protection rating
Dettaglio
Product with IK08 mechanical impact rating
Dettaglio
This product is available in RGBW LED
Dettaglio
Product dimmable DALI
Dettaglio
Dimmable CASAMBI available on request
Light effect
effect NARROW NARROW effect MEDIUM MEDIUM effect WIDE WIDE effect ELLIPTICAL ELLIPTICAL
effect
NARROW
Simulation made with Oblò
21,0 W 3000K
Optics: 9°
Code: 8488411
Distance from wall: 2.5 m
Distance between products: 4 m
Wall height: 5 m

effect
MEDIUM
Simulation made with Oblò
21,0 W 3000K
Optics: 28°
Code: 8488413
Distance from wall: 2.5 m
Distance between products: 4 m
Wall height: 5 m

effect
WIDE
Simulation made with Oblò
21,0 W 3000K
Optics: 45°
Code: 8488418
Distance from wall: 2.5 m
Distance between products: 4 m
Wall height: 5 m

effect
ELLIPTICAL
Simulation made with Oblò
21,0 W 3000K
Optics: Elliptical
Code: 8488417
Distance from wall: 2.5 m
Distance between products: 4 m
Wall height: 5 m

Select your product
Use the filters to choose the most suitable product for your needs
Oblò
Oblò
DISCOVER
Oblò
Oblò
DISCOVER
Hide filters View filters
Luminous flux range
Colour temperature
CRI
Dimmable
Power Supply Unit
Beam angle
Optical accessories
Beam aperture
Use the filters to find the most suitable aperture beam for your needs, among those available.
Super spot
Super spot
Medium
Medium
Medium-Wide
Medium-Wide
Elliptical
Elliptical
Product code Description "Source" power Plug-in power max Optics Dimmable Power supply
product
8488491i Oblò - 12 LED 2700K 9° 19,0 W 21,0 W 9° Not dimmable 220 ÷ 240V
product
8488411i Oblò - 12 LED 3000K 9° 19,0 W 21,0 W 9° Not dimmable 220 ÷ 240V
product
8488461i Oblò - 12 LED 4000K 9° 19,0 W 21,0 W 9° Not dimmable 220 ÷ 240V
product
8488493i Oblò - 12 LED 2700K 28° 19,0 W 21,0 W 28° Not dimmable 220 ÷ 240V
product
8488413i Oblò - 12 LED 3000K 28° 19,0 W 21,0 W 28° Not dimmable 220 ÷ 240V
product
8488463i Oblò - 12 LED 4000K 28° 19,0 W 21,0 W 28° Not dimmable 220 ÷ 240V
product
8488498i Oblò - 12 LED 2700K 45° 19,0 W 21,0 W 45° Not dimmable 220 ÷ 240V
product
8488418i Oblò - 12 LED 3000K 45° 19,0 W 21,0 W 45° Not dimmable 220 ÷ 240V
product
8488468i Oblò - 12 LED 4000K 45° 19,0 W 21,0 W 45° Not dimmable 220 ÷ 240V
product
8488497i Oblò - 12 LED 2700K Elliptical 19,0 W 21,0 W Elliptical Not dimmable 220 ÷ 240V
product
8488417i Oblò - 12 LED 3000K Elliptical 19,0 W 21,0 W Elliptical Not dimmable 220 ÷ 240V
product
8488467i Oblò - 12 LED 4000K Elliptical 19,0 W 21,0 W Elliptical Not dimmable 220 ÷ 240V
product
8388401i Oblò - 16 LED RGBW 9° Max 16,0 W Max 16,0 W 9° PWM Max 350mA (4 channels + 1 channel NTC)
product
8388403i Oblò - 16 LED RGBW 28° Max 16,0 W Max 16,0 W 28° PWM Max 350mA (4 channels + 1 channel NTC)
product
8388408i Oblò - 16 LED RGBW 45° Max 16,0 W Max 16,0 W 45° PWM Max 350mA (4 channels + 1 channel NTC)
product
8388407i Oblò - 16 LED RGBW Elliptical Max 16,0 W Max 16,0 W Elliptical PWM Max 350mA (4 channels + 1 channel NTC)
