Micro
Micro
Die-cast body manufactured in EN 44300 aluminium alloy with very low copper content and locking trim in AISI 316L stainless steel. No visible screws and fixing with spring locking system. Subjected to galvanic anodizing treatment divided into distinct phases: mechanical satin finishing, surface degreasing, anodic oxidation and final sealing. The product is painted following a continuous two step paint process (epoxy-based primer + polyester-based colour finish), which allows to generate a single thick protective coating which then generates aprotective barrier against atmospheric agents and UV rays. IP68 protection with Full Dry system which avoids condensation inside the product.
- IP65/68 (2m)
- IK10
- LED
5,9 W 3000K
Optics: RS 12°
Code: 8430911
Distance from wall: 0.7 metres
Distance between products: 3 metres
Wall height: 3 metres
5,9 W 3000K
Optics: RS 33°
Code: 8430913
Distance from wall: 0.7 metres
Distance between products: 3 metres
Wall height: 3 metres
5,9 W 3000K
Optics: RS 44°
Code: 8430918
Distance from wall: 0.7 metres
Distance between products: 3 metres
Wall height: 3 metres
2,0 W 3000K
Optics: ASY
Code: 8430019
Distance from wall: 0.7 metres
Distance between products: 3 metres
Wall height: 3 metres
| Product code | Description | LED wattage | System wattage | Optics | Dimmable | Power supply | ||
|---|---|---|---|---|---|---|---|---|
|
8430991 | Micro ceiling recessed - 3 LED 2700K RS 12° | 5,0 W | 5,9 W | RS 12° | TRIAC | 220 ÷ 240V | |
|
|
8430911 | Micro ceiling recessed - 3 LED 3000K RS 12° | 5,0 W | 5,9 W | RS 12° | TRIAC | 220 ÷ 240V | |
|
|
8430961 | Micro ceiling recessed - 3 LED 4000K RS 12° | 5,0 W | 5,9 W | RS 12° | TRIAC | 220 ÷ 240V | |
|
|
8430993 | Micro ceiling recessed - 3 LED 2700K RS 33° | 5,0 W | 5,9 W | RS 33° | TRIAC | 220 ÷ 240V | |
|
|
8430913 | Micro ceiling recessed - 3 LED 3000K RS 33° | 5,0 W | 5,9 W | RS 33° | TRIAC | 220 ÷ 240V | |
|
|
8430963 | Micro ceiling recessed - 3 LED 4000K RS 33° | 5,0 W | 5,9 W | RS 33° | TRIAC | 220 ÷ 240V | |
|
|
8430998 | Micro ceiling recessed - 3 LED 2700K RS 44° | 5,0 W | 5,9 W | RS 44° | TRIAC | 220 ÷ 240V | |
|
|
8430918 | Micro ceiling recessed - 3 LED 3000K RS 44° | 5,0 W | 5,9 W | RS 44° | TRIAC | 220 ÷ 240V | |
|
|
8430968 | Micro ceiling recessed - 3 LED 4000K RS 44° | 5,0 W | 5,9 W | RS 44° | TRIAC | 220 ÷ 240V | |
|
|
8430099 | Micro ceiling recessed - 1 LED 2700K ASY | Max 2,0 W | Max 2,0 W | ASY | PWM | Max 700mA | |
|
|
8430019 | Micro ceiling recessed - 1 LED 3000K ASY | Max 2,0 W | Max 2,0 W | ASY | PWM | Max 700mA | |
|
|
8430069 | Micro ceiling recessed - 1 LED 4000K ASY | Max 2,0 W | Max 2,0 W | ASY | PWM | Max 700mA | |
|
|
8330101 | Micro ceiling recessed - 4 LED RGBW RS 12° | Max 6,0 W | Max 6,0 W | RS 12° | PWM | Max 500mA (4 channels + 1 channel NTC) | |
|
|
8330103 | Micro ceiling recessed - 4 LED RGBW RS 38° | Max 6,0 W | Max 6,0 W | RS 38° | PWM | Max 500mA (4 channels + 1 channel NTC) | |
|
|
8330108 | Micro ceiling recessed - 4 LED RGBW RS 44° | Max 6,0 W | Max 6,0 W | RS 44° | PWM | Max 500mA (4 channels + 1 channel NTC) |
