Die-cast body and flange manufactured in EN 44300 aluminium alloy with very low copper content. Subjected to galvanic anodizing treatment divided into distinct phases: mechanical satin finishing, surface degreasing, anodic oxidation and final sealing. The product is painted following a continuous two step paint process (epoxy-based primer + polyester-based colour finish), which allows to generate a single thick protective coating which then generates aprotective barrier against atmospheric agents and UV rays. Before fixing the diffuser on the Platek products a Pre-treatment using an atmospheric pressure plasma process is carried out on the surface. The process activates the ionic load on the surface exactly where it is needed, thus promoting the best silicone grip possible and removing any residual release of agents for a longer lasting seal. The next steps are the coating of silicone and the assembly of the diffuser on the lighting fixture, with an automated process to guarantee the perfect sealing of the lamp.




| Product code | Description | LED wattage | System wattage | Optics | Dimmable | Power supply | ||
|---|---|---|---|---|---|---|---|---|
| 1517391 | One floodlight - 9 LED 2700K 9° | 18,0 W | 21,0 W | 9° | DALI | 220 ÷ 240V | ||
| 1517311 | One floodlight - 9 LED 3000K 9° | 18,0 W | 21,0 W | 9° | DALI | 220 ÷ 240V | ||
| 1517361 | One floodlight - 9 LED 4000K 9° | 18,0 W | 21,0 W | 9° | DALI | 220 ÷ 240V | ||
| 1517393 | One floodlight - 9 LED 2700K 25° | 18,0 W | 21,0 W | 25° | DALI | 220 ÷ 240V | ||
| 1517363 | One floodlight - 9 LED 4000K 25° | 18,0 W | 21,0 W | 25° | DALI | 220 ÷ 240V | ||
| 1517313 | One floodlight - 9 LED 3000K 25° | 18,0 W | 21,0 W | 25° | DALI | 220 ÷ 240V | ||
| 1517398 | One floodlight - 9 LED 2700K 48° | 18,0 W | 21,0 W | 48° | DALI | 220 ÷ 240V | ||
| 1517318 | One floodlight - 9 LED 3000K 48° | 18,0 W | 21,0 W | 48° | DALI | 220 ÷ 240V | ||
| 1517368 | One floodlight - 9 LED 4000K 48° | 18,0 W | 21,0 W | 48° | DALI | 220 ÷ 240V | ||
| 1517397 | One floodlight - 9 LED 2700K Elliptical | 18,0 W | 21,0 W | Elliptical | DALI | 220 ÷ 240V | ||
| 1517317 | One floodlight - 9 LED 3000K Elliptical | 18,0 W | 21,0 W | Elliptical | DALI | 220 ÷ 240V | ||
| 1517367 | One floodlight - 9 LED 4000K Elliptical | 18,0 W | 21,0 W | Elliptical | DALI | 220 ÷ 240V | ||
| 8349401 | One floodlight - 16 LED RGBW 9° | Max 23,0 W | Max 23,0 W | 9° | PWM | Max 500mA (4 channels + 1 channel NTC) | ||
| 8349403 | One floodlight - 16 LED RGBW 28° | Max 23,0 W | Max 23,0 W | 28° | PWM | Max 500mA (4 channels + 1 channel NTC) | ||
| 8349408 | One floodlight - 16 LED RGBW 45° | Max 23,0 W | Max 23,0 W | 45° | PWM | Max 500mA (4 channels + 1 channel NTC) | ||
| 8349407 | One floodlight - 16 LED RGBW Elliptical | Max 23,0 W | Max 23,0 W | Elliptical | PWM | Max 500mA (4 channels + 1 channel NTC) |
